PULVERISETTE 6 Planetary Mill premium line
PULVERISETTE 6 Planetary Mill premium line with 2 working stations is a high-performance all-rounder in routine laboratory work. It is the ideal mill for fast wet and dry grinding of hard, medium-hard, soft, brittle and moist samples as well as for mechanical alloying, mixing and homogenising of larger sample quantities with reliable results down into the nano range.
FEATURES
- Extra strong 2.2 kW drive power and extremely high centrifugal acceleration up to 64 g and up to 800 rpm (rotational speed of the bowl 1,600 rpm)
- Maximum operational safety due to ServoLOCK clamping of the grinding bowls
- Blocking of the mill in the event of impermissible operating states
- Automatic shutoff function if an imbalance occurs.
- Reliable bowl detection via RFID chip and optimization of grinding speeds via RFID-Chip
- Safely guided insertion of grinding bowls
- Safe opening in the event of overpressure
- Intuitive touchscreen operation with colour display
- Simultaneous processing of up to 4 samples
- Useful capacity up to 2 x 225 ml
- Up to 10 programmes can be saved, software MillControl (optional), USB inter face for transmission of process parameters
- Extensive accessories for simplifying your daily work
PULVERISETTE 6 classic line
PULVERISETTE 6 classic line is a high-performance Planetary Ball Mill with a single grinding bowl mount and practical, easily adjustable imbalance compensation. Your advantage: Particularly easy use and high-energy effect of up to 650 rpm. This ensures a constantly high grinding performance with extremely low space requirements for loss-free grinding results for the comminution of hard, medium-hard, brittle and moist materials, dry in suspension or in inert gas and is ideally suited for mechanical alloying or for mixing and perfect homogenising of emulsions and pastes.
FEATURES
- Special grinding force due to a rotational speed of up to 650 rpm
- Low space requirements and ergonomic design
- Particularly easy-to-use
- Timer programming precise to ± one second
- Simultaneous processing of up to 2 samples
- Useful capacity up to 225 ml
- Large rotational speed range with accurate display
- Easy to open grinding chamber completely encapsulated
- Cooling of the grinding chamber with a built-in fan for long grinding times
- Exactly reproducible grinding results thanks to a regulated drive, precise transmission ratio (toothed belt), programmable microprocessor control electronic
- Programmable interval and pause times
- Smaller grinding bowls also possible with an adapter
- RS232 interface for outputting process data (validation)
- Monitoring of the grinding parameters even when grinding chamber is open through an ergonomically positioned and always visible, splash-proof IP65 membrane keyboard
- Easy cleaning of the grinding elements
- Energy-save-function (electricity-saving mode)
- Extensive accessories for simplifying your daily work
For more details please visit the Fritsch Website
Alternatively download the Pulverisette 6 Product Brochure
